POWER ACOUSTIK EG1-2500D MONO BLOCK CAR AMPLIFIER
- Car Audio Class-D Monoblock 1-Ohm Stable Amplifier
- Model: EG1-2500D
- RMS Power:
- 4 ohms: 400 watts x 1 channel
- 2 ohms: 800 watts x 1 channel
- 1 ohm: 1250 watts x 1 channel
- Total power output: 2500 watts
- Military Grade PCB w/ PWM MOSFET power supply
- LED power (green) and protect (red) indicators
- Soft start turn-on
- Mono channel operation
- Preamp RCA outputs to daisy chain multiple amps
- 3-way protection circuitry (thermal, overload, and speaker short protection)
- Dual speaker terminals simplify the hookup of multiple speakers
- Input sensitivity:
- Low level: 0.2V-2V
- High level: 2-8V
- Variable low-pass filter: 30 - 250 Hz
- Subsonic filter: 20 - 50 Hz
- Variable Bass Boost: 0 to +18 dB bass boost
- Fuse Rating: 60 A x 2
- Dimensions: 9"W x 10"L x 2.25"H
