IMAGE DYNAMICS IDQS10 D4 10" DUAL 4 OHM SHALLOW MOUNT CAR SUBWOOFER
Image Dynamics
$ 25599$ 255.99
Unit price/ per
Car Audio 10-inch Dual voice coil 4-ohm Shallow mount Subwoofer
Model: IDQS10D4 IDQ Series
RMS Power Handling: 200 watts
PEAK Power Handling: 350 watts
VC Impedance: 4-Ohms + 4-Ohms
Test Impedance: 2-Ohm
Driver Displacement: 0.054
Fs: 50 Hz
Spl: 84 dB
Xmax: 7.5mm
Voice Coil: 2.0"
Voice Coil Height: 0.98"
Voice Coil Type: Kapton Former
Voice Coil Wire: Copper
DC Resistance: 1.9 Ohms
Voice Coil Induct at 1kHz: 0.34 MH
Frequency Response: 50-500Hz
Resonant Freq: 50 Fs Hz
HE-Magnetic Gap Height: 0.393"
Motor Structure: 42.95 oz
High Excursion Design allows acoustically linear bass output at all rated power levels.
Parabolic Santoprene Surround to ensure cone linearity and control.
Poly/Mica Cone for strong and distortion free bass reproduction while still reproducing all the musical nuances.
Nomex Spider for consistent control throughout the piston range and life of the woofer.
Poly Carbonate Neck Joint allows the woofer to handle more raw power without any mechanical failure or flex and isolate the heat from the BASV voice coil former from the cone.
American Made Flat Wound Extended Voice Coil gives our woofers higher magnetic flux (strength) and more voice coil “traction” in the magnetic gap with over 1.75” of linear travel in the magnetic gap.
Extended Y-35 Motor Structure allows the voice coil to move freely without any mechanical bottoming out while producing a very powerful flux field.
